F-260-S/F-270-S Full Body Immersıon Tanks
F-260-S Full Body Immersion Tank
Whitehall Model F-260 Full Body Immersion Tank is recommended for debridement of burn patients and others requiring carefully controlled water temperature and/or total immersion hydrotherapy.
Tank Capacity is 260 gallons.
Whirlpool Tank is 95”L x 41”W x 22”D and is seamless welded construction, fabricated from heavy gauge, type 304 stainless steel, polished to a satin finish. Tank bottom is a rounded covered design to minimize bacteria buildup with a reinforced stainless steel base supported by adjustable stainless steel legs.
Tank fittings are two 1-1/4” OD overflows, one 1-1/4” NPT filler spout, one lever operated quick open/close drain valve and an adjustable head rest.
Turbine Raising and Lowering Device permits adjustment of desired height and direction of water agitation towards the area of the body to be treated. It is spring balanced and provided with a locking device.
Turbine Assembly functions both as agitator and emptying device. It is equipped with Underwriters Laboratory listed 1/2 HP jet pump motor protected with an ABS plastic shell, and automatic thermal overload protector, and lifetime-sealed bearings. All parts contacting the water are stainless steel, chrome plated brass or bronze.
Thermometer is provided with a dual scale, adjustable calibration, and a stem inserts into a retainer to prevent rattle during whirlpool agitation.
F-270-S Full Body Immersion Tank
Whitehall Model F-270-S Full Body Immersion Tank is recommended for treatment of upper and lower extremities permitting patients full body immersion, room for body motion and exercise.
This Hubbard style tank with figure “8” configuration allows therapists easy access to assure patient comfort.
Tank Capacity is 270 gallons.
Hubbard Tank figure “8” configuration is overall 93”L x 64”W x 22”D and is seamless welded construction, fabricated from heavy gauge, type 304 stainless steel, polished to a satin finish. Tank bottom is a rounded covered design to minimize bacteria buildup.
Tank has a reinforced stainless steel base supported by adjustable stainless steel legs. Tank fittings are two1-1/4” OD overflows, one 1-1/4” NPT filler spout, one lever operated quick open/close drain valve and an adjustable head rest.
Turbine Raising and Lowering Device permits adjustment of desired height and direction of water agitation towards the area of the body to be treated. It is spring balanced and provided with a locking device.
Twin Turbine Assemblies are mounted on carriages with automatic counter balance. Assemblies may be moved along the tank length for the most advantageous treatment position. Each assembly is equipped with Underwriters Laboratory listed 1/2 HP jet pump motor protected with an ABS plastic shell, and automatic thermal overload protector, and lifetime sealed bearings. All parts contacting the water are stainless steel, chrome plated brass or bronze.
Thermometer is provided with a dual scale, adjustable calibration, and a stem inserts into a retainer to prevent rattle during whirlpool agitation.
